Used Winkworth PV63-25 63 litre stainless steel process vessel

Description

Used Winkworth model PV63-25, approximately 63 litre stainless steel process vessel. The unit has a welded flat top and a conical welded bottom. It measures approximately 600mm in diameter x 450mm straight side. Internal rated design pressure: 3 bar. Jacket rated design pressure: 5 bar. The unit has a top entry stainless steel contra-rotating gate agitator driven by two motors: a 1.1 kW geared motor producing 33.6 rpm and a 0.75 kW geared motor producing 76.4 rpm. The unit has a bottom entry offset Silverson BE275 homogeniser with a square hole disintegrating head driven by a 0.75 kW motor. It has a local control panel and is mounted on a stand with four legs.
