Tissue Paper Machine 2.65m / 104" Wide

Description

Used Tissue Paper Machine with a Crescent Former:

Width: 2650 mm (104 inches)
Speed: 500 m/min (1640 ft/min)
Capacity: 30 TPD (33 short tons/day)
Basis Weight: 13–32 gsm (8–20 lbs/3000 ft²)

Supply includes:
- Close headbox with 20,000 l/min flow rate
- Vacuum forming section
- Suction press roll
- Yankee cylinder: diameter 3200 mm, width 2800 mm
- High efficiency hood with heat recovery system, width 2800 mm
- Pope reeler, width 2800 mm, for jumbo rolls diameter (1270–1778 mm) and core diameter 76 mm
