Unused 3V Tech Model BE6300 Vertical Glass Lined Reactor

Description

Unused 3V Tech type BE6300 (Short Type) vertical glass-lined reactor. Approximately 6,870 litre total capacity with approximately 5,350 litre working capacity (Product Dependent). Unit has welded dished top and bottom heads. Unit measures approximately 2,000 mm diameter x 1,800 mm straight side. Internal rated 6 bar/full vacuum design pressure at -25 to 200 °C. External mild steel jacket 510 litre total capacity with approximately 487 litre working capacity, rated 6 bar/full vacuum design pressure at -25 to 200 °C. Glass lining is 3V Tech Sigma Anti-Static Conductive blue glass. Unit has top entry 3-blade press-lock glass-lined anti-static conductive glass agitator with top-mounted drive/gearbox. Includes top-mounted internal baffle. Unit is mounted on four mild steel side support lugs.
