Used vertical stainless steel AISI 316 silos with a total capacity of 2930 litres. The tank has an internal diameter of 1260 mm and a straight wall length of 2150 mm. The bolted flat top is equipped with a central inlet with a diameter of 460 mm and an inspection manway with a diameter of 300 mm without a cover, along with two connections. The welded conical bottom is 600 mm high and has a central discharge outlet with a pneumatically operated butterfly valve by WAMGROUP, type V2FS150AI, with an internal diameter of 145 mm. Two nozzles are mounted in the conical bottom for blowing off the cone from the inside. The silo has one level sensor mounted in the lower part of the side wall. The silo is mounted on four lugs.
