18,000 Litre, 2 Bar Internal, 3 Bar Jacket, 304 Stainless Steel Reactor
Have one to sell?
ConditionUsed
5 available
Used FBM 18,000 litre 304 stainless steel vertical reactor. Internal dimensions approximately 2,984 mm diameter x 3,098 mm over dished ends. Features a bolted dished top head and a welded dished bottom head. Internally rated for 2.5 bar design pressure. Carbon steel limpet coil jacket rated for 3.5 bar design pressure. Equipped with an anchor agitator directly driven by a 33/45 kW motor and gearbox at 13/26 rpm. Includes six 168 mm diameter x 2,000 mm long dip pipes, providing 6 square metres of heat transfer area. Mounted on four lugs.
