Vanguard VHZ-20B Semi-Automatic Carton Box Packing Machine

Description

Unused Vanguard Model VHZ-20B semi-automatic carton box packing machine. Commonly used in a wide range of applications in the pharmaceutical, food, cosmetics, nutraceutical and chemical industries. It can pack cartons or cases into boxes automatically.
The VHZ-120B is cylinder-driven and uses a photo-detection system to drive all parts to work in perfect harmony. The machine’s compact structure is easy to adjust, with high quality and reliable operation that conforms to FDA and cGMP standards.

Packing material: corrugated paper
Max. 120 boxes/hr.
Production capacity for packed products:
Min box size (L×W×H): 50 mm × 20 mm × 12 mm
Max size (L×W×H): 330 mm × 500 mm × 65 mm
Production capacity for cartons (inner):
Min size (L×W×H): 185 mm × 95 mm × 115 mm
Max size (L×W×H): 560 mm × 340 mm × 390 mm
Machine dimensions: 2200 mm × 2150 mm × 1900 mm
Main machine weight: 1210 lbs
