Used approximately 20-gallon 304 stainless steel autoclave. 13¼" diameter x 24" long on straight side. With flat bottom top with packing gland. 2 HP DC agitator drive with an 8" diameter and an 8½" diameter turbine-type blades. Gearbox ratio 5:1. Bottom dished head with 2" flange outlet. Maximum design pressure 275 psi at 100°F. Maximum design temperature 400°F at 180 psi. Head thickness 0.375". All mounted on 46" high steel legs. Manufactured by Pacific Pipe Co. Year: 1968. Serial #523. HBS583/S.D. Co. Serial #61468.
