110" (2,794 mm) Tissue Converting Line, Complete

Description

Used 110" (2,794 mm) wide tissue converting line featuring BAOSUO Rewinder, PCMC Tail Sealer, Ultra-S250 Log Saw & Core Winder. The line includes the following major components:

1) BAOSUO Model Ultra Grand 110" (2,794 mm) Rewinder (2010)
Designed for kitchen roll towel and bath tissue production. Currently configured for bath tissue only. Equipped with Mitsubishi motion control and PLC.
Includes cutoff knife and support for large-diameter cores for hardwound roll towel and jumbo roll tissue.
Sectional drive motor: 20 kW (26.8 HP)
Laminator rubber-to-steel embosser with 48 kW (64.4 HP) drive motor
Also features water lamination system, quick-exchange emboss cassette, automatic core loader, and log accumulator with 150-log capacity.
Line speeds:
2-ply with water lamination: 350–400 m/min (1,150–1,310 ft/min)
2-ply with ply bonding: 400–450 m/min (1,310–1,475 ft/min)
Single-ply: 450–530 m/min (1,475–1,740 ft/min)
OEM: BAOSUO (China)

2) PCMC Roto Seal Tail Sealer (S/N M-2536). High-speed, upgraded model. Capable of sealing up to 40 logs per minute.
2.1) PCMC Roto Seal high Speed tail sealer model TS03-02, upgraded independent unit, with Allen Bradley PLC, has an additional prep roll for up to 60 logs per minute, S/N NG402889

3) Ultra-S250 Log Saw (Upgraded 2020, S/N 19A19002FS)
4-lane continuous motion log saw with shuttle trim removal.
Design speed: 250 cuts/min
Running speed: approx. 220 cuts/min
Includes touchscreen interface.
OEM: China

4) 90-Degree Turn Conveyor
Approx. 2.1 m (7 ft) long x 762 mm (30 in) wide. Fitted with sensors and guard rails.
OEM: Unknown

5) Hytrol Power Belt Conveyor
Approx. 3.35 m (11 ft) long x 762 mm (30 in) wide.
OEM: Hytrol Conveyor Co. (USA)
Crossover Ladder

6) BAOSUO Core Winder Model C-100
Servo-controlled cut-off saw with Ronco single-position unwind stand featuring tension control and hoist.
Max roll diameter: 1,524 mm (60 in)
Paper width: 98 mm (3-7/8 in)
Upgraded with Ronco 4600 extruded glue system for single-ply cores. Equipped with Allen Bradley touchscreen PLC control and Valco Melton glue head.
OEM: BAOSUO (China)

7) Infinity IG20 Case Gluer (2016, S/N M-680-CS-F1-0315)
Case gluer with Allen Bradley electrical controls and Nordson ProBlue 7 hot melt system.
7.1) Infinity IG20 Case Gluer (2016, S/N M-681-CS-F1-0315)
Case gluer with Allen Bradley electrical controls and Nordson ProBlue 7 hot melt system.
Speed: 20 cases per minute
OEM: Infinity Machine & Engineering (USA)

8) Infinity Product Tipping Conveyor (Model IAT-50, S/N T-1504-103-F1-0315)
For proper orientation before case packing.
Dimensions: 2.9 m (9.5 ft) long x 610 mm (24 in) wide
OEM: Infinity Machine & Engineering (USA)

9) Infinity Smart Conveyor (Model TC1-12, S/N T-1504-105-F1-031)
Dimensions: 3.05 m (10 ft) long x 305 mm (12 in) wide
OEM: Infinity Machine & Engineering (USA)
