120 Gallon Werner & Pfleiderer Stainless Steel Sigma Blade Mixer/Extruder

Description

Used Werner & Pfleiderer Mixer/Extruder Type UK450-A3
10" diameter X 59" long
304 Stainless steel mixing arms
Working capacity: 120 gallons (450 liters)
Total capacity: 175.6 gallons (675 liters)
Oil Jacketed
Carbon steel jacketed bowl 37-3/4" front to back X 33" left to right X approximate 30" deep
Domed top cover, suitable for vacuum
347 Stainless steel tangential sigma blades with 4.7" diameter (120 mm) shafts
Driven by (2) 50 hp Baldor motors
50 hp motor for mixing arms
50 hp motor for discharge, ~5’ Length
Blade speed 16/22 rpm via Kestermann gearbox
Gearbox internals stainless steel
Gearbox lube strainer 16-22 rpm
