54 l Vertical Mixing Tank With Heating Jacket By Terlet

Description

Used stainless steel boiling tank by Terlet (NL) with total volume 54 l and working volume about 45 l. Contact parts designed in stainless steel. Tank has internal diameter 450 mm x length of straight side of wall 340 mm. Bottom flat, with side wall discharge outlet equipped with manually operated valve. Top open, equipped with manually operated lid. Tank has bottom and side walls layered with heating jacket and thermal insulation. Inside the tank there is mounted bottom driven frame type agitator with side wall scrappers. Agitator is driven by el motor 0.37 kW, 1390 rpm, 230/400 V, 50 hz and gearbox. Tank is mounted on supporting stainless steel frame. There is also included with machine a perforated stainless steel basket .
