Used Eimco model 9624 horizontal belt filter with 316 stainless steel and fiberglass reinforced plastic contacts. 25 HP varispeed Reeves drive and 43/1 gearbox. Roller chain drive from gearbox to head pulley. Belt speed variable from 6-48' per minute. 192 sq. ft. of filtering area. All unitized on a structural steel I-beam frame. Included is an accessory package including Bingham type 6-M vacuum pump with 150 HP 3/60/230-460/1750 rpm motor, (2) 3" centrifugal filtrate pumps with 10 HP motors, (2) 42" diameter X 7' high steel filtrate tanks, 550 gallon steel surge tank, 8' DIA. X 8' high 3000 gallon vertical plastic feed tank. All accessories are mounted on a dual tandom axle trailer.
