1000 L Stainless Steel Conical Powder Mixer Pharming

Description

Used stainless steel conical powder mixer, Nauta type, by Pharming, model HV 1000 (CZ). The cone has a diameter of 1550 mm and a height of 2200 mm. The total volume of the tank is approximately 1830 litres, with a working volume of up to 1000 litres.
Total height is 340 cm. The standard mixing screw is top-driven by an electric motor, 3 kW, 970 rpm, 230-400 V, 50 Hz, and supported by a bottom pintle bearing. Arm rotation speed is 2 rpm. Screw rotation speed is 60 rpm.
Central bottom discharge via slide outlet valve, operated pneumatically. The top of the mixer has a bolted stainless steel cover equipped with two feeding hoppers. One has inlet dimensions of 200 mm x 410 mm, the second inlet measures 350 mm x 500 mm. Each hopper has a connection diameter of 190 mm, and the top cover is manually opened. Half of the top cover is missing.
The mixer is mounted on four lugs. Technical documentation is included. Shipping dimensions: length 340 cm x diameter 170 cm x weight approximately 1000 kg. The machine has been in use in the food industry.
