Used mixing station for liquids. The station consists of a vertical stainless steel mixing tank with a total volume of 1300 litres. Internal diameter 1170 mm × length of straight side of wall 1140 mm. Bottom ellipsoidal, with central discharge outlet. The tank is mounted on three stainless steel legs, on load cells. Four baffles are welded to the side walls. Mixing is provided by a homogenising agitator by IKA (DE), model Turrax UTC TMP 150 / 2KT, driven directly by 11 kW, 2915 rpm, 380/660 V, 50 Hz. Length of the shaft 900 mm × diameter of mixing die 150 mm. The agitator is mounted on a stainless steel supporting frame. Discharge from the tank is provided by a sinusoidal stainless steel contact parts pump by Masosine Process Pumps, model SP 25, working at pressures up to 15 bar. Working rotation up to 600 rpm. Pump is driven by 2.2 kW, 1400 rpm, 220–380 V, 50 Hz. Working rotation of drive up to 233 rpm. Pump has connections (inlet/outlet) with diameter 80 mm. The station also includes a stainless steel container lifter by Nagema (DE). Working lifting height up to 150 cm. Unit can work with rectangular containers with a width of 70 cm. The station is equipped with two control panels. It was last used in the food industry.
